Use standard parts and save time
Solid Edge Standard Parts Library
CAD Partner GmbH has been closely collaborating with Siemens Digital Industries Software in the field of standard parts for many years and, in this context, developed the Solid Edge Standard Parts Library. The leading CAD software and the library form a unified system, with an integration depth that leaves nothing to be desired.
Companies across all industries that use Solid Edge for mechanical design and work with standard parts benefit from this time-saving and labor-reducing addition to their 3D CAD software. The standard parts library offers a wide range of intelligent components and ensures optimal functionality: All Solid Edge features are supported, and the same system requirements set in Solid Edge apply to the standard parts.
The benefits of the Solid Edge Standard Parts Library:
Purchase the standard parts library
You can acquire the Solid Edge Standard Parts Library directly through the global resellers of Siemens Digital Industries Software solutions.
PartFinder – The quick access to all standard parts within the company
PartFinder is a database-based management solution for all standard and purchased parts and is an integral part of the Solid Edge Standard Parts Library. Its efficient and intuitive interface ensures quick access to the desired components. The management of custom factory standard parts or purchased parts is possible through the customizable attribute bar.
The Packages
The standard parts are available as packages, allowing you to select only the ones you actually need. This makes the design process clearer for the user and reduces the administrative effort for the administrator. The following packages are available:
-
Bolts
-
Stock
-
Pencils
-
Profiles
-
Plant Engineering
Supported Standards
Standard parts are used worldwide. Naturally, different national standards are supported:
-
DIN, DIN EN
-
ANSI, ASME, ABMA, ASTM, MSS
-
ISO
-
GB
-
JIS
-
KS
-
GOST
-
BS
-
UNI
-
CSN
-
IS
